Frontend-Backend Communication Wire Protocol

·872 words·5 mins· ·
Ruohang Feng
Author
Ruohang Feng
Pigsty Founder, @Vonng
Table of Contents

Understanding the TCP protocol used for communication between PostgreSQL server and client


Startup Phase
#

The basic flow of the startup phase is as follows:

  • Client sends a StartupMessage (F) to initiate connection request to server

    Payload includes 0x30000 Int32 version number magic, and a series of kv-structured runtime parameters (NULL0 separated, required parameter is user),

  • Client waits for server response, mainly waiting for ReadyForQuery (Z) event sent by server, which represents that server is ready to receive requests.

The above are the two main events in connection establishment process. Other events include authentication messages AuthenticationXXX (R), backend key messages BackendKeyData (K), error messages ErrorResponse (E), and a series of context-independent messages (NoticeResponse (N), NotificationResponse (A), ParameterStatus(S))

We can write a Go program to simulate this process:

package main

import (
	"fmt"
	"net"
	"time"

	"github.com/jackc/pgx/pgproto3"
)

func GetFrontend(address string) *pgproto3.Frontend {
	conn, _ := (&net.Dialer{KeepAlive: 5 * time.Minute}).Dial("tcp4", address)
	frontend, _ := pgproto3.NewFrontend(conn, conn)
	return frontend
}

func main() {
	frontend := GetFrontend("127.0.0.1:5432")

	// Establish connection
	startupMsg := &pgproto3.StartupMessage{
		ProtocolVersion: pgproto3.ProtocolVersionNumber,
		Parameters:      map[string]string{"user": "vonng"},
	}
	frontend.Send(startupMsg)

	// Startup process, receiving ReadyForQuery message indicates startup process completion
	for {
		msg, _ := frontend.Receive()
		fmt.Printf("%T %v\n", msg, msg)
		if _, ok := msg.(*pgproto3.ReadyForQuery); ok {
			fmt.Println("[STARTUP] connection established")
			break
		}
	}

	// Simple query protocol
	simpleQueryMsg := &pgproto3.Query{String: `SELECT 1 as a;`}
	frontend.Send(simpleQueryMsg)
	// Receiving CommandComplete message indicates query completion
	for {
		msg, _ := frontend.Receive()
		fmt.Printf("%T %v\n", msg, msg)
		if _, ok := msg.(*pgproto3.CommandComplete); ok {
			fmt.Println("[QUERY] query complete")
			break
		}
	}
}

Output result:

*pgproto3.Authentication &{0 [0 0 0 0] [] []}
*pgproto3.ParameterStatus &{application_name }
*pgproto3.ParameterStatus &{client_encoding UTF8}
*pgproto3.ParameterStatus &{DateStyle ISO, MDY}
*pgproto3.ParameterStatus &{integer_datetimes on}
*pgproto3.ParameterStatus &{IntervalStyle postgres}
*pgproto3.ParameterStatus &{is_superuser on}
*pgproto3.ParameterStatus &{server_encoding UTF8}
*pgproto3.ParameterStatus &{server_version 11.3}
*pgproto3.ParameterStatus &{session_authorization vonng}
*pgproto3.ParameterStatus &{standard_conforming_strings on}
*pgproto3.ParameterStatus &{TimeZone PRC}
*pgproto3.BackendKeyData &{35703 345830596}
*pgproto3.ReadyForQuery &{73}
[STARTUP] connection established
*pgproto3.RowDescription &{[{a 0 0 23 4 -1 0}]}
*pgproto3.DataRow &{[[49]]}
*pgproto3.CommandComplete &{SELECT 1}
[QUERY] query complete

Connection Proxy
#

Based on jackc/pgx/pgproto3, you can easily write some middleware. For example, the following code is a very simple “connection proxy”:

package main

import (
	"io"
	"net"
	"strings"
	"time"

	"github.com/jackc/pgx/pgproto3"
)

type ProxyServer struct {
	UpstreamAddr string
	ListenAddr   string
	Listener     net.Listener
	Dialer       net.Dialer
}

func NewProxyServer(listenAddr, upstreamAddr string) *ProxyServer {
	ln, _ := net.Listen(`tcp4`, listenAddr)
	return &ProxyServer{
		ListenAddr:   listenAddr,
		UpstreamAddr: upstreamAddr,
		Listener:     ln,
		Dialer:       net.Dialer{KeepAlive: 1 * time.Minute},
	}
}

func (ps *ProxyServer) Serve() error {
	for {
		conn, err := ps.Listener.Accept()
		if err != nil {
			panic(err)
		}
		go ps.ServeOne(conn)
	}
}

func (ps *ProxyServer) ServeOne(clientConn net.Conn) error {
	backend, _ := pgproto3.NewBackend(clientConn, clientConn)
	startupMsg, err := backend.ReceiveStartupMessage()
	if err != nil && strings.Contains(err.Error(), "ssl") {
		if _, err := clientConn.Write([]byte(`N`)); err != nil {
			panic(err)
		}
		// ssl is not welcome, now receive real startup msg
		startupMsg, err = backend.ReceiveStartupMessage()
		if err != nil {
			panic(err)
		}
	}

	serverConn, _ := ps.Dialer.Dial(`tcp4`, ps.UpstreamAddr)
	frontend, _ := pgproto3.NewFrontend(serverConn, serverConn)
	frontend.Send(startupMsg)

	errChan := make(chan error, 2)
	go func() {
		_, err := io.Copy(clientConn, serverConn)
		errChan <- err
	}()
	go func() {
		_, err := io.Copy(serverConn, clientConn)
		errChan <- err
	}()

	return <-errChan
}

func main() {
	proxy := NewProxyServer("127.0.0.1:5433", "127.0.0.1:5432")
	proxy.Serve()
}

Here the proxy listens on port 5433 and parses and forwards messages to the real database server on port 5432. Execute the following command in another session:

$ psql postgres://127.0.0.1:5433/data?sslmode=disable -c 'SELECT * FROM pg_stat_activity LIMIT 1;'

You can observe message exchanges during this process:

[B2F] *pgproto3.ParameterStatus &{application_name psql}
[B2F] *pgproto3.ParameterStatus &{client_encoding UTF8}
[B2F] *pgproto3.ParameterStatus &{DateStyle ISO, MDY}
[B2F] *pgproto3.ParameterStatus &{integer_datetimes on}
[B2F] *pgproto3.ParameterStatus &{IntervalStyle postgres}
[B2F] *pgproto3.ParameterStatus &{is_superuser on}
[B2F] *pgproto3.ParameterStatus &{server_encoding UTF8}
[B2F] *pgproto3.ParameterStatus &{server_version 11.3}
[B2F] *pgproto3.ParameterStatus &{session_authorization vonng}
[B2F] *pgproto3.ParameterStatus &{standard_conforming_strings on}
[B2F] *pgproto3.ParameterStatus &{TimeZone PRC}
[B2F] *pgproto3.BackendKeyData &{41588 1354047533}
[B2F] *pgproto3.ReadyForQuery &{73}
[F2B] *pgproto3.Query &{SELECT * FROM pg_stat_activity LIMIT 1;}
[B2F] *pgproto3.RowDescription &{[{datid 11750 1 26 4 -1 0} {datname 11750 2 19 64 -1 0} {pid 11750 3 23 4 -1 0} {usesysid 11750 4 26 4 -1 0} {usename 11750 5 19 64 -1 0} {application_name 11750 6 25 -1 -1 0} {client_addr 11750 7 869 -1 -1 0} {client_hostname 11750 8 25 -1 -1 0} {client_port 11750 9 23 4 -1 0} {backend_start 11750 10 1184 8 -1 0} {xact_start 11750 11 1184 8 -1 0} {query_start 11750 12 1184 8 -1 0} {state_change 11750 13 1184 8 -1 0} {wait_event_type 11750 14 25 -1 -1 0} {wait_event 11750 15 25 -1 -1 0} {state 11750 16 25 -1 -1 0} {backend_xid 11750 17 28 4 -1 0} {backend_xmin 11750 18 28 4 -1 0} {query 11750 19 25 -1 -1 0} {backend_type 11750 20 25 -1 -1 0}]}
[B2F] *pgproto3.DataRow &{[[] [] [52 56 55 52] [] [] [] [] [] [] [50 48 49 57 45 48 53 45 49 56 32 50 48 58 52 56 58 49 57 46 51 50 55 50 54 55 43 48 56] [] [] [] [65 99 116 105 118 105 116 121] [65 117 116 111 86 97 99 117 117 109 77 97 105 110] [] [] [] [] [97 117 116 111 118 97 99 117 117 109 32 108 97 117 110 99 104 101 114]]}
[B2F] *pgproto3.CommandComplete &{SELECT 1}
[B2F] *pgproto3.ReadyForQuery &{73}
[F2B] *pgproto3.Terminate &{}
