PostgreSQL Development Convention (2018 Edition)

·3438 words·17 mins· ·
Ruohang Feng
Author
Ruohang Feng
Pigsty Founder, @Vonng
Table of Contents

0x00 Background
#

Without rules, there can be no order.

PostgreSQL is extremely powerful, but to use PostgreSQL well requires coordinated effort from backend developers, operations teams, and DBAs.

This article compiles a development specification based on PostgreSQL database principles and features, hoping to reduce confusion encountered when using PostgreSQL. Good for you, good for me, good for everyone.

0x01 Naming Conventions
#

The nameless is the beginning of heaven and earth; the named is the mother of all things.

【Mandatory】 General Naming Rules

  • This rule applies to all object names, including: database names, table names, column names, function names, view names, sequence names, aliases, etc.
  • Object names must only use lowercase letters, underscores, numbers, but must start with a lowercase letter. Regular tables are prohibited from starting with _.
  • Object names must not exceed 63 characters, naming uniformly adopts snake_case.
  • Prohibited to use SQL reserved words. Use select pg_get_keywords(); to get reserved keyword list.
  • Prohibited to use dollar signs, Chinese characters, don’t start with pg.
  • Improve vocabulary taste, be clear and elegant; don’t use pinyin, don’t use obscure words, don’t use niche abbreviations.

【Mandatory】 Database Naming Rules

  • Database names should ideally match the application or service, must be highly distinctive English words.
  • Naming must start with <biz>-, where <biz> is the specific business line name. If it’s a shard database, it must end with -shard.
  • Multiple parts connected with -. Examples: <biz>-chat-shard, <biz>-payment, etc., no more than three segments total.

【Mandatory】 Role Naming Conventions

  • Database su has one and only one: postgres. User for streaming replication named replication.
  • Production users use <biz>- as prefix, specific function as suffix.
  • All databases have three basic roles by default: <biz>-read, <biz>-write, <biz>-usage, with read-only, write-only, and function execution permissions for all tables respectively.
  • Production users, ETL users, and personal users obtain permissions by inheriting corresponding basic roles.
  • More fine-grained permission control uses independent roles and users, varies by business.

【Mandatory】 Schema Naming Rules

  • Business uniformly uses <*> as schema name, where <*> is business-defined name, must be set as first element of search_path.
  • dba, monitor, trash are reserved schema names.
  • Shard schema naming rule: rel_<partition_total_num>_<partition_index>.
  • No special reason to create objects in other schemas.

【Recommended】 Relation Naming Rules

  • Relation naming should prioritize clear meaning, don’t use ambiguous abbreviations, shouldn’t be overly lengthy, follow general naming rules.
  • Table names should use plural nouns, consistent with historical conventions, but avoid words with irregular plural forms.
  • Views use v_ as naming prefix, materialized views use mv_ as naming prefix, temporary tables use tmp_ as naming prefix.
  • Inherited or partition tables should use parent table name as prefix, with child table characteristics (rules, shard ranges, etc.) as suffix.

【Recommended】 Index Naming Rules

  • When creating indexes, if possible specify index names and maintain consistency with PostgreSQL default naming rules to avoid creating duplicate indexes on repeated execution.
  • Indexes for primary keys end with _pkey, unique indexes end with _key, indexes for EXCLUDED constraints end with _excl, regular indexes end with _idx.

【Recommended】 Function Naming Rules

  • Start with select, insert, delete, update, upsert to indicate action type.
  • Important parameters can be reflected in function names through suffixes like _by_ids, _by_user_ids.
  • Avoid function overloading, keep only one function with the same name.
  • Prohibited to overload through BIGINT/INTEGER/SMALLINT integer types, may cause ambiguity when calling.

【Recommended】 Field Naming Rules

  • Must not use system column reserved field names: oid, xmin, xmax, cmin, cmax, ctid, etc.
  • Primary key columns usually named id, or use id as suffix.
  • Creation time usually named created_time, modification time usually named updated_time.
  • Boolean fields suggest using is_, has_ etc. as prefixes.
  • Other field names need to maintain consistency with existing table naming conventions.

【Recommended】 Variable Naming Rules

  • Variables in stored procedures and functions use named parameters, not positional parameters.
  • If parameter names conflict with object names, add _ after parameter, e.g., user_id_.

【Recommended】 Comment Conventions

  • Try to provide comments (COMMENT) for objects, comments use English, concise and clear, preferably one line.
  • When object schema or content semantics change, must update comments accordingly, keeping in sync with actual situation.

0x02 Design Conventions
#

Suum cuique

【Mandatory】 Character encoding must be UTF8

  • Prohibited to use any other character encoding.

【Mandatory】 Capacity Planning

  • Single table over 100 million records, or exceeding 10GB scale, consider starting table partitioning.
  • Single table capacity over 1T, single database capacity over 2T. Need to consider sharding.

【Mandatory】 Don’t abuse stored procedures

  • Stored procedures suitable for encapsulating transactions, reducing concurrency conflicts, reducing network round trips, reducing return data volume, executing small amounts of custom logic.
  • Stored procedures not suitable for complex calculations, not suitable for trivial/frequent type conversions and wrapping.

【Mandatory】 Storage-compute separation

  • Remove unnecessary compute-intensive logic from database, such as using SQL in database for WGS84 to other coordinate system conversions.
  • Exception: Computational logic closely related to data retrieval and filtering allowed in database, such as geometric relationship judgments in PostGIS.

【Mandatory】 Primary keys and identity columns

  • Every table must have identity column, in principle must have primary key, minimum requirement is having non-null unique constraint.
  • Identity column used to uniquely identify any tuple in table, logical replication and many third-party tools depend on this.

【Mandatory】 Foreign keys

  • Not recommended to use foreign keys, suggest solving at application layer. When using foreign keys, references must set corresponding actions: SET NULL, SET DEFAULT, CASCADE, use cascade operations carefully.

【Mandatory】 Use wide tables carefully

  • Tables with more than 15 fields considered wide tables, wide tables should consider vertical splitting, referencing each other through same primary key with main table.
  • Due to MVCC mechanism, write amplification in wide tables is quite obvious, try to reduce frequent updates to wide tables.

【Mandatory】 Configure appropriate default values

  • Columns with default values must add DEFAULT clause specifying default value.
  • Can use functions in default values to dynamically generate default values (e.g., primary key generators).

【Mandatory】 Properly handle null values

  • Fields with no semantic distinction between zero and null values don’t allow null values, must configure NOT NULL constraint for columns.

【Mandatory】 Unique constraints enforced by database

  • Unique constraints must be guaranteed by database, any unique column must have unique constraint.
  • EXCLUDE constraint is generalized unique constraint, can be used to ensure data integrity in low-frequency update scenarios.

【Mandatory】 Pay attention to integer overflow risk

  • Note that SQL standard doesn’t provide unsigned integer types, values exceeding INTMAX but not UINTMAX need upgraded storage.
  • Don’t store values exceeding INT64MAX in BIGINT columns, will overflow to negative numbers.

【Mandatory】 Unified timezone

  • Use TIMESTAMP to store time, use utc timezone.
  • Uniformly use ISO-8601 format for inputting/outputting time types: 2006-01-02 15:04:05, avoid DMY vs MDY issues.
  • When using TIMESTAMPTZ, use GMT/UTC time, 0 timezone standard time.

【Mandatory】 Timely cleanup of outdated functions

  • Functions no longer used or replaced should be taken offline promptly to avoid conflicts with future functions.

【Recommended】 Primary key types

  • Primary keys usually use integer type, recommend using BIGINT, allow using strings no longer than 64 bytes.
  • Primary keys allow using Serial auto-generation, recommend using Default next_id() generator functions.

【Recommended】 Choose appropriate types

  • When specialized types can be used, don’t use strings. (Numbers, enums, network addresses, currency, JSON, UUID, etc.)
  • Using correct data types can significantly improve data storage, query, index, computation efficiency, and improve maintainability.

【Recommended】 Use enum types

  • Relatively stable fields with small value space (within a dozen) should use enum types, don’t use integers and strings to represent.
  • Using enum types has advantages in performance, storage, and maintainability.

【Recommended】 Choose appropriate text types

  • PostgreSQL text types include char(n), varchar(n), text.
  • Usually recommend using varchar or text. Types with (n) modifier check string length, causing minor additional overhead. When string length limits are needed, use varchar(n) to avoid inserting overly long dirty data.
  • Avoid using char(n). For SQL standard compatibility, this type has unintuitive behavior (padding spaces and truncation), and has no storage or performance advantages.

【Recommended】 Choose appropriate numeric types

  • Regular numeric fields use INTEGER. Primary keys, capacity uncertain numeric columns use BIGINT.
  • Don’t use SMALLINT without special reason, performance and storage improvements are minimal, will have many additional problems.
  • REAL represents 4-byte floating point, FLOAT represents 8-byte floating point
  • Floating point numbers only usable in scenarios where end precision doesn’t matter, such as geographic coordinates. Don’t use equality comparisons on floating point numbers.
  • Exact numeric types use NUMERIC, pay attention to precision and decimal place settings.
  • Monetary numeric types use MONEY.

【Recommended】 Use unified function creation syntax

  • Signature occupies separate line (function name and parameters), return value starts new line, language as first tag.
  • Must annotate function volatility level: IMMUTABLE, STABLE, VOLATILE.
  • Add definite attribute tags, such as: RETURNS NULL ON NULL INPUT, PARALLEL SAFE, ROWS 1, pay attention to version compatibility.
CREATE OR REPLACE FUNCTION
  nspname.myfunc(arg1_ TEXT, arg2_ INTEGER)
  RETURNS VOID
LANGUAGE SQL
STABLE
PARALLEL SAFE
ROWS 1
RETURNS NULL ON NULL INPUT
AS $function$
SELECT 1;
$function$;

【Recommended】 Design for evolvability

  • When designing tables, should fully consider future expansion needs, can appropriately add 1-3 reserved fields when creating tables.
  • For variable non-critical fields, can use JSON type.

【Recommended】 Choose reasonable normalization level

  • Allow appropriately reducing normalization level, reducing multi-table joins to improve performance.

【Recommended】 Use new versions

  • New versions have cost-free performance improvements, stability improvements, more new features.
  • Fully utilize new features, reduce design complexity.

【Recommended】 Use triggers carefully

  • Triggers increase system complexity and maintenance costs, not encouraged.

0x03 Index Conventions
#

Wer Ordnung hält, ist nur zu faul zum Suchen.

【Mandatory】 Online queries must have supporting indexes

  • All online queries must design corresponding indexes for their access patterns, full table scans not allowed except for very few small tables.
  • Indexes have costs, not allowed to create unused indexes.

【Mandatory】 Prohibited to build indexes on large fields

  • Indexed field size cannot exceed 2KB (1/3 page capacity), in principle prohibited to exceed 64 characters.
  • If large field indexing needed, consider hashing large fields and building function indexes. Or use other types of indexes (GIN).

【Mandatory】 Specify null value sorting rules

  • If sorting needed on nullable columns, need to explicitly specify NULLS FIRST or NULLS LAST in queries and indexes.
  • Note that default rule for DESC sorting is NULLS FIRST, meaning null values appear at the front of sort, usually not desired behavior.
  • Index sorting conditions must match query, such as: create index on tbl (id desc nulls last);

【Mandatory】 Use GiST indexes for nearest neighbor queries

  • Traditional B-tree indexes cannot provide good support for KNN problems, should use GiST indexes.

【Recommended】 Utilize function indexes

  • Any redundant fields that can be inferred from other fields in the same row can use function indexes instead.
  • For statements frequently using expressions as query conditions, can use expression or function indexes to accelerate queries.
  • Typical scenarios: Build hash function indexes on large fields, build reverse function indexes for text columns needing left fuzzy queries.

【Recommended】 Utilize partial indexes

  • Fixed parts in query conditions can use partial indexes, reducing index size and improving query efficiency.
  • If indexed field in query has only limited few values, can also build several corresponding partial indexes.

【Recommended】 Utilize range indexes

  • For data where values are linearly correlated with heap table storage order, if usual queries are range queries, recommend using BRIN indexes.
  • Most typical scenario is append-only time series data, BRIN indexes more efficient.

【Recommended】 Pay attention to composite index selectivity

  • Put columns with high selectivity first.

0x04 Query Conventions
#

The limits of my language mean the limits of my world.

—Ludwig Wittgenstein

【Mandatory】 Read-write separation

  • In principle, write requests go to primary, read requests go to replica.
  • Exception: Need read-your-own-write consistency guarantee, and significant replication lag detected.

【Mandatory】 Fast-slow separation

  • Queries within 1ms in production called fast queries, queries over 1 second in production called slow queries.
  • Slow queries must go to offline replica, must set appropriate timeouts.
  • Online regular query execution time in production should in principle be controlled within 1ms.
  • Online regular query execution time in production exceeding 10ms needs technical solution modification, optimize to standard before going online.
  • Online queries should configure 10ms level or faster timeouts, avoid accumulation causing avalanche.
  • Master and Slave roles not allowed to bulk pull data, data warehouse ETL programs should pull data from Offline replicas.

【Mandatory】 Active timeout

  • Configure active timeout for all statements, actively cancel requests after timeout to avoid avalanche.
  • Periodically executed statements must configure timeout smaller than execution period.

【Mandatory】 Pay attention to replication lag

  • Applications must be aware of sync lag between primary and replica, and properly handle situations where replication lag exceeds reasonable range.
  • Usually 0.1ms lag can reach tens of minutes or even hours in extreme cases. Applications can choose to read from primary, retry later, or report error.

【Mandatory】 Use connection pooling

  • Applications must access database through connection pooling, connect to port 6432’s pgbouncer instead of port 5432’s postgres.
  • Note differences between using connection pooling vs direct database connection, some features may not be available (like Notify/Listen), may also have connection pollution issues.

【Mandatory】 Prohibited to modify connection state

  • When using public connection pools, prohibited to modify connection state, including modifying connection parameters, changing search path, switching roles, switching databases.
  • If absolutely necessary to modify, must completely destroy connection. Returning state-changed connections to connection pool will cause pollution spread.

【Mandatory】 Retry failed transactions

  • Queries may be killed due to concurrency contention, admin commands, etc. Applications need to be aware of this and retry when necessary.
  • Applications can trigger circuit breaker when database reports many errors, avoid avalanche. But pay attention to distinguishing error types and nature.

【Mandatory】 Reconnect on disconnect

  • Connections may be terminated for various reasons, applications must have disconnect-reconnect mechanism.
  • Can use SELECT 1 as heartbeat query to check connection liveness and keep alive regularly.

【Mandatory】 Online service application code prohibited from executing DDL

  • Don’t make big news in application code.

【Mandatory】 Explicitly specify column names

  • Avoid using SELECT *, or using * in RETURNING clauses. Please use specific field lists, don’t return unused fields. When table structure changes (e.g., new columns), queries using column wildcards may experience column count mismatch errors.
  • Exception: When stored procedures return specific table row types, wildcards allowed.

【Mandatory】 Prohibited full table scans in online queries

  • Exceptions: constant tiny tables, extremely low frequency operations, tables/result sets very small (within hundreds of records/hundreds of KB).
  • Using negation operators like !=, <> in first-level filter conditions causes full table scans, must avoid.

【Mandatory】 Prohibited long waits in transactions

  • Must commit or rollback promptly after starting transaction, IDLE IN Transaction over 10 minutes will be forcibly killed.
  • Applications should enable AutoCommit, avoid unpaired ROLLBACK or COMMIT after BEGIN.
  • Try to use standard library provided transaction infrastructure, don’t manually control transactions unless absolutely necessary.

【Mandatory】 Must close cursors promptly after use

【Mandatory】 Scientific counting

  • count(*) is standard syntax for counting rows, unrelated to null values.
  • count(col) counts non-null records in col column. NULL values in this column not counted.
  • count(distinct col) distinct count on col column, also ignores null values, only counts non-null distinct values.
  • count((col1, col2)) multi-column count, even if counted columns are all null will be counted, (NULL,NULL) valid.
  • count(distinct (col1, col2)) multi-column distinct count, even if counted columns all null will be counted, (NULL,NULL) valid.

【Mandatory】 Pay attention to null value issues in aggregate functions

  • All aggregate functions except count ignore null value inputs, so when all input values are null, result is NULL. But count(col) returns 0 in this case, an exception.
  • If aggregate function returning null is not desired result, use coalesce to set default value.

【Mandatory】Handle null values carefully

  • Clearly distinguish zero values from null values, null values use IS NULL for equality judgment, zero values use regular = operator for equality judgment.
  • When null values serve as function input parameters, should have type modifiers, otherwise overloaded functions cannot identify which to use.
  • Pay attention to null value comparison logic: any comparison operation involving null values results in unknown, need to pay attention to unknown participating in boolean operations:
    • and: TRUE or UNKNOWN returns TRUE due to logical short-circuit.
    • or: FALSE and UNKNOWN returns FALSE due to logical short-circuit
    • Other cases where operands have UNKNOWN, results are all UNKNOWN
  • Logical judgment between null values and any value results in null value, e.g., NULL=NULL returns NULL not TRUE/FALSE.
  • For equality comparisons involving null and non-null values, use IS DISTINCT FROM for comparison, ensuring non-null comparison results.
  • Null values and aggregate functions: aggregate functions return NULL when all input values are NULL.

【Mandatory】 Pay attention to sequence number gaps

  • When using Serial type, operations like INSERT, UPSERT consume sequence numbers, this consumption won’t rollback with transaction failure.
  • When using integers as primary keys and table has frequent insert conflicts, need to pay attention to integer overflow issues.

【Recommended】 Use prepared statements for repeated queries

  • Repeated queries should use prepared statements, eliminating database hard parsing CPU overhead.
  • Prepared statements modify connection state, pay attention to connection pool impact on prepared statements.

【Recommended】 Choose appropriate transaction isolation level

  • Default isolation level is read committed, suitable for most simple read-write transactions, regular transactions choose minimum isolation level meeting requirements.
  • Write transactions needing transaction-level consistent snapshots, use repeatable read isolation level.
  • Write transactions with strict correctness requirements use serializable isolation level.
  • When concurrency conflicts occur in RR and SR isolation levels, should actively retry based on error type.

【Recommended】 Don’t use count to judge result existence

  • Use SELECT 1 FROM tbl WHERE xxx LIMIT 1 to judge if records meeting conditions exist, faster than Count.
  • Can use select exists(select * FROM app.sjqq where xxx limit 1) to convert existence result to boolean value.

【Recommended】 Use RETURNING clause

  • If users need to immediately get inserted, deleted, or modified data after inserting, before deleting, or after modifying data, recommend using RETURNING clause to reduce database interactions.

【Recommended】 Use UPSERT to simplify logic

  • When business has insert-fail-update operation sequences, consider using UPSERT instead.

【Recommended】 Use advisory locks for hotspot concurrency

  • For extremely high frequency concurrent writes to single records (flash sales), should use advisory locks to lock record IDs.
  • If high concurrency contention can be solved at application layer, don’t put it at database layer.

【Recommended】Optimize IN operator

  • Use EXISTS clause instead of IN operator for better results.
  • Use =ANY(ARRAY[1,2,3,4]) instead of IN (1,2,3,4) for better results.

【Recommended】 Left fuzzy search not recommended

  • Left fuzzy search WHERE col LIKE '%xxx' cannot fully utilize B-tree indexes, if needed, can use reverse expression function indexes.

【Recommended】 Use arrays instead of temporary tables

  • Consider using arrays instead of temporary tables, e.g., when getting corresponding records for a series of IDs. =ANY(ARRAY[1,2,3]) better than temporary table JOIN.

0x05 Release Conventions
#

【Mandatory】 Release format

  • Currently submit releases via email, send emails to dba@p1.com for archiving and scheduling.
  • Clear title: xx project needs to execute xx action in xx database.
  • Clear objectives: each step needs to execute what operations on which instances, how to verify results.
  • Rollback plan: any changes need to provide rollback plan, new creations also need cleanup scripts.

【Mandatory】Release evaluation

  • Online database releases need to go through developer self-testing, supervisor review, (optional QA review), DBA review evaluation stages.
  • Self-testing stage should ensure changes execute correctly in development and pre-production environments.
    • If creating new tables, should provide record quantity scale, daily data increment estimates, read-write volume estimates.
    • If creating new functions, should provide stress test reports, at least need average execution time.
    • If schema migration, must clearly sort out all upstream and downstream dependencies.
  • Team Leader needs to evaluate and review changes, responsible for change content.
  • DBA evaluates and reviews release format and impact.

【Mandatory】 Release window

  • No database releases allowed after 19:00, emergency releases require TL special explanation, copy CTO.
  • Requirements confirmed after 16:00 will be postponed to next day. (Based on TL confirmation time)

0x06 Management Conventions
#

【Mandatory】 Pay attention to backups

  • Daily full backups, continuous archiving of WAL segments

【Mandatory】 Pay attention to age

  • Pay attention to database and table age, avoid transaction ID wraparound.

【Mandatory】 Pay attention to aging and bloat

  • Pay attention to table and index bloat rates, avoid performance degradation.

【Mandatory】 Pay attention to replication lag

  • Monitor replication lag, must pay special attention when using replication slots.

【Mandatory】 Follow minimum privilege principle

【Mandatory】Create and drop indexes concurrently

  • For production tables, must use CREATE INDEX CONCURRENTLY to create indexes concurrently.

【Mandatory】 New replica data prewarming

  • Use pg_prewarm, or gradually introduce traffic.

【Mandatory】 Carefully perform schema changes

  • When adding new columns must use syntax without default values, avoid full table rewrite
  • When changing types, must rebuild all functions depending on that type when necessary.

【Recommended】 Split large batch operations

  • Large batch write operations should be split into small batches, avoid generating large amounts of WAL at once.

【Recommended】 Accelerate data loading

  • Turn off autovacuum, use COPY to load data.
  • Build constraints and indexes afterwards.
  • Increase maintenance_work_mem, increase max_wal_size.
  • Execute vacuum verbose analyze table after completion.

Related

Efficient Administrative Region Lookup with PostGIS
·2180 words·11 mins
How to efficiently solve the typical reverse geocoding problem: determining administrative regions based on user coordinates.
KNN Ultimate Optimization: From RDS to PostGIS
·4114 words·20 mins
Ultimate optimization of KNN problems, from traditional relational design to PostGIS
Distinct On: Remove Duplicate Data
·557 words·3 mins
Use Distinct On extension clause to quickly find records with maximum/minimum values within groups
Function Volatility Classification Levels
·644 words·4 mins
PostgreSQL functions have three volatility levels by default. Proper use can significantly improve performance.
Implementing Mutual Exclusion Constraints with Exclude
·854 words·5 mins
Exclude constraint is a PostgreSQL extension that can implement more advanced and sophisticated database constraints.
Implementing Cache Synchronization with Go and PostgreSQL
·1234 words·6 mins
Cleverly utilizing PostgreSQL’s Notify feature, you can conveniently notify applications of metadata changes and implement trigger-based logical replication.
